synthetic zeolite 13x molecular sieve CAS NO.63231-69-6
- Min.Order: 0 Metric Ton
- Payment Terms: L/C,T/T
- Product Details
Keywords
- zeolite 13x
- synthetic zeolite
- molecular sieve 13x
Quick Details
- ProName: synthetic zeolite 13x molecular sieve
- CasNo: 63231-69-6
- Molecular Formula: 3/4CaO*1/4Na2O*Al2O3*2SiO2*9/2H2O
- Application: Natural gas, liquefied petroleum gas, ...
- Port: Any China Port
- ProductionCapacity: Metric Ton/Day
- Purity: 97%
- LimitNum: 0 Metric Ton
- Grade: Industrial Grade
Superiority
|
Item |
Unit |
Bead |
Pellet |
|||
|
Mesh |
|
8*12 |
4*8 |
1/16’’ |
1/8’’ |
|
|
Diameter |
mm |
1.6-2.5 |
3.0-5.0 |
1.5-1.8 |
2.8-3.2 |
|
|
Bulk Density |
g/ml≥ |
0.72 |
0.68 |
0.62 |
0.62 |
|
|
Equilibrium Water Capacity ( 25℃) |
wt%≥ |
27 |
27 |
26 |
26 |
|
|
Equilibrium Carbon Dioxide Capacity |
wt%≥ |
18 |
18 |
17.5 |
17.5 |
|
|
Heat of Adsorption |
BTU/lb of H2O |
1800 |
1800 |
1800 |
1800 |
|
|
Crush Strength |
Point contact |
N≥ |
35 |
80 |
30 |
75 |
|
|
Variation coefficient |
- |
0.3 |
0.3 |
0.4 |
0.4 |
|
Attrition Rate |
wt%≤ |
0.1 |
0.1 |
0.3 |
0.3 |
|
|
Size Qualification |
%≥ |
97 |
97 |
97 |
97 |
|
|
Package Moisture |
wt%≤ |
1.5 |
1.5 |
1.5 |
1.5 |
|
Details
Molecular sieve 13X is applied in the desiccating process of industrial gas and gas purification in air separation unit ,mainly aiming for the removal of H2O,CO2 and hydrocarbon gases. To meet the special requirements of the cryogenic air separation industry, we improve the ability to absorb carbon dioxide and water so as to avoid the occurrence of cold tower phenomenon in air separation process. Molecular sieve 13 X has the characteristics of high CO2 adsorption capacity, low regeneration temperature and long service life.
